Users can enable/disable external control in this menu option.
An external voltage source (VOLT) or resistor (RES) can be
used to control the output voltage and current. The external
voltage/resistance can be either 0 - 10V/0 - 10K (10V/10K) or
0 - 5V/0 - 5K (5V/5K). Users can also monitor the output
status by reading the monitoring pins (0 - 10V or 0 - 5V) of the
external analog control interface.
7. TIMER CONTROL
Press
in the third page of menu to enter TIMER CONTROL
screen.
TIMER:
Turn on/off TIMER function.
TIME:
Set up OUTPUT ON time (Max:999Hr 59Min
59Sec)
8. CALIBRATION
Press
in the third page of the menu to enter CALIBRATION
menu. Users must enter the password to access calibration mode. For
calibration details, see āCalibrationā chapter.
9
. Series Connection Control Setting (CHAIN)
Press in Menu setting page to enter CHAIN SETTING
