C. Please inspect the hardware if the current value is inconsistent with

the value in the tolerance error table below after the calibration

values of each function is changed to actual current value.

XLN3640

Function Setting Range of Transformation Value

0.1A

0 - 0.5 A

MIDL

13A

11 - 14 A

MIDH

26A

23 - 27 A

38A

34 - 39 A

XLN6024

Function Setting Range of Transformation Value

0.06A

0 - 0.5 A

MIDL

7.8A

6.6 - 9 A

MIDH

15.6A

14 - 17.2 A

22.8A

21 - 24.6 A

XLN8018

Function Setting Range of Transformation Value

Lo 0.045A 0 - 0.1 A

MIDL 5.9A 5.3 - 6.5 A

MIDH 12A 10.8 - 13.2 A

Hi 17A 15.3 - 18.7 A

CALIB CURR MIDH = 258.246 mV

CALIB CURR Hi = 377.559 mV
