96
Parameter List
System Parameters
Displayed
Name Available Settings
Factory Default Setting
(Initial Value)
SYSTEM
LCD Contrast
LCD Contrast
1–16 16
Patch Extent
Patch Extent
Start: 1–99
End: 1–99
Start: 1
End: 99
Knob Mode
Knob Mode
IMMEDIATE, CURRENT SETTING,
KNOB POSITION
IMMEDIATE
Auto Rec Trigger
Auto Recording Trigger Level
0–100 50
REC Pdl Act
REC Pedal Action
REC
→
PLAY, REC
→
OVERDUB REC
→
PLAY
Input Out
Input Output Select
PATCH, MAIN, SUB, MAIN+SUB,
MUTE
PATCH
Phrase1, 2, 3 Out
Phrase 1, 2, 3 Output Select
PATCH, MAIN, SUB, MAIN+SUB PATCH
Guide Out
Guide Output Select
PATCH, MAIN, SUB, MAIN+SUB PATCH
PresetProtct
Preset Protect
OFF, ON ON
MIDI
MIDI Rx Ch
MIDI Receive Channel 1–16 1
MIDI Omni MIDI Omni Mode OFF, ON ON
MIDI Tx Ch MIDI Transmit Channel 1–16, RX RX
MIDI Sync MIDI Sync
PATCH, AUTO, INTERNAL,
REMOTE
PATCH
MIDI PC Out MIDI Program Change Out OFF, ON ON
MIDI CC Out MIDI Control Change Out OFF, ON ON
PEDAL
TEMPO Func: SYS
TEMPO Pedal Function Refer to p. 71 PATCH TEMPO (TAP)
UNDO Func: SYS UNDO/REDO Pedal Function Refer to p. 71 UNDO/REDO
CTL1 Func: SYS CTL1 Pedal Function Refer to p. 71 GUIDE START/STOP
CTL2 Func: SYS CTL2 Pedal Function Refer to p. 71 ALL START/STOP
CTL3 Func: SYS CTL3 Pedal Function Refer to p. 71 CURRENT CLEAR
CTL4 Func: SYS CTL4 Pedal Function Refer to p. 71 OVERDUB MODE INC
EXP Func: SYS EXP Pedal Function Refer to p. 72 PATCH LEVEL
EXP Level Min: SYS EXP Pedal Min Level 0–200 0
EXP Level Max: SYS EXP Pedal Max Level 0–200 100
EXP Tempo Min: SYS EXP Pedal Tempo Min 40.0–250.0 40.0
EXP Tempo Max: SYS EXP Pedal Tempo Min 40.0–250.0 250.0
CC#1 Func: SYS CC#1 Function Refer to p. 78 OFF
CC#7 Func: SYS CC#7 Function Refer to p. 78 OFF
CC#80 Func: SYS CC#80 Function Refer to p. 78 OFF
