Broadcom NetXtreme User Manual

Broadcom NetXtreme Ethernet Adapter • Diagnostic User’s Guide
page 64
Broadcom Confidential and Proprietary
Disable(2) When PXE is disable the expansion ROM enable bit in the PCI
configuration space is cleared for system boot up. The PXE code does
NOT have to been load into the non-volatile memory of the device.
9
PXE Link Speed
Configure
Description:
Pre-Boot Execution Environment line configuration is specified using the parameters
below. Options 8,9, 26 - 29 and 39-40 configure the boot protocol behavior.
Auto(0) PXE auto detects the link configuration.
10HD(1) PXE uses a 10 Mbits/s, half duplex line configuration.
10FD(2) PXE uses a 10 Mbits/s, full duplex line configuration.
100HD(3) PXE uses a 100 Mbits/s, half duplex line configuration.
100FD(4) PXE uses a 100 Mbits/s, full duplex line configuration.
10
Magic Packet WoL
Configure
Description:
A system can be configured to power-on when a Magic Packet is received.
Enable(1) The device will assert the pme signal, to power on the system, when a
magic packet is received.
Disable(2) Magic packets are ignored.
Note:
A driver can setup the WoL behavior of a device and the value programmed into this
location is ignored.
11
Product Name
Reference
Description:
VPD Product description string.
12
Part Number
Reference
Description:
VPD part number..
13
Engineering Change
Reference
Description:
VPD engineering change.
14
Serial Number
Reference
Description:
VPD serial number.
15
Manufacturing ID
Reference
Description:
VPD manufacturing ID.
16
Asset Tag
Reference
Description:
VPD asset tag.
17
Part Revision
Reference
Description:
VPD part revision.
18
Voltage (5701 only)
Configure
Description:
Controls the voltage source level for the 5701 controller.
1.3V(0) Selects a 1.3V source.
1.8V(1) Selects a 1.8V source.
