Broadcom NetXtreme Ethernet Adapter • Diagnostic User’s Guide
page 77
Broadcom Confidential and Proprietary
3. Data3: 3.3v, PME Aux, D3, 0.4 Watt
4. Data4: Unused
5. Data5: Unused
6. Data6: Unused
7. Data7: Unused
-------------------------------------- Custom VPD Prod.Name (option e)----------------------------------------
-> e
Selfboot VPD R
1. Use system default
2. Costom define
-> 2
1. Part Number : BCM957xx
2. Engineering Change : 106679-15
3. Serial Number : 0123456789
4. Manufacturing ID : 14e4
5. Read only VPD Vendor Specific Data (V0) :
6. Product Name :
Description of above parameters:
To enter the ‘secfg’ menu shown above a user type in ‘secfg’ for selfboot firmware at the
diagnostics command line. A menu is present to the user showing the ‘secfg’ options shown
above. A user can change the ‘secfg’ parameter by entering the option number.
The tables below provide details for each parameter of the ‘secfg’ options for selfboot
firmware. The top right of each table has the word “Configure” or “Reference”.
“Configure” signifies that the option is used to configure the operating characteristics of the
device or default values of registers in the device. “Reference” signifies that the option is
use for display purposes and does not affect the operating characteristics of the device or
default values of registers in the device.
1
MAC Address
Configure
Description:
MAC address of the device.
2
Device ID
Configure
Description:
PCI Device ID.
3
Subsystem Vendor ID
Configure
Description:
PCI Subsystem PCI Vendor ID.
4
Subsystem Device ID
Configure
Description:
PCI Subsystem PCI Device ID.
