Broadcom NetXtreme User Manual

Broadcom NetXtreme Ethernet Adapter • Diagnostic User’s Guide
page 80
Broadcom Confidential and Proprietary
e-6
Product Name
Reference
Description:
VPD Product description string.
g
Cable Sense
Configure
Description:
Enables a low power mode (IDDQ) of the chip which allows the presence of a cable to be
detected by the chip (valid for 5752M/5755M/5787M/5787FM devices). Once Cable Sense
is enabled GPIO3 will be an Energy Detect Output Pin and will be high if a cable (with a
signal present) is plugged into the RJ45 and low otherwise.
Disable (0) Disable cable sense.
Enable (1) Enable cable sense.
Card reader only options:
l
SD3.0
Configure
Description:
Enable/Disable SD 3.0
Disable (0) Disable
Enable (1) Enable
n
SD Bus Power/LED CTRL
Configure
Description:
Configure CR LED pin as SD Bus power or LED Ctrl.
Bus power (0) Bus power
LED (1) LED Ctrl
f
VPD Data
Configure
Description:
VPD data
Part Number (1) BCM95751
Engineering Change (2) 106679-15
Serial Number (3) 0123456789
Manufacturing ID(4)
14e4
Read only Vendor Data (5)
Product Name
Broadcom NetXtreme Gigabit Ethernet Controller
h
MBA Configuration
Configure
Description:
MBA Configuration
VLan Enable (1) Enabled / Disabled
VLan ID (2) VLan ID
MBA Hide Banner (3) Enabled / Disabled
MBA Hot Key (4)
Ctrl-B / Ctrl-S
MBA Protocol (5)
PXE / RPL / BOOTP / ISCSI
MBA Config Timeout (6) MBA Config Timeout value
MBA Bootstrap (7) Auto / BBS / INT18 / INT19
MBA Link Speed (8) Auto /10HD / 10FD / 100HD / 100FD
Remove MBA Config (9) 0: No 1:Yes
