Broadcom NetXtreme User Manual

Broadcom NetXtreme Ethernet Adapter • Diagnostic User’s Guide
page 81
Broadcom Confidential and Proprietary
o
SD LED Output CTRL
Configure
Description:
Configure SD LED output
Active High (0) Active High
Active Low (1) Active Low
Open Drain (2) Open Drain
Open Collector (3) Open Collector
p
SD Bus Power Output Polarity
Configure
Description:
Configure SD Bus power output polarity
Active High (0) Active High
Active Low (1) Active Low
q
SD Write Protect Polarity
Configure
Description:
Configure SD Write Protect Polarity.
Active High (0) Active High
Active Low (1) Active Low
s
Memory Stick INS Polarity
Configure
Description:
Configure Memory Stick INS Polarity.
Active High (0) Active High
Active Low (1) Active Low
t
Memory Stick INS Chip Pull-up/Pull-down Override
Configure
Description:
Configure Memory Stick INS internal Chip Pull-up/Pull-down override.
Disable (0) Disable override
Activate Pull-up and
deactivate Pull-down (1)
Activate Pull-up and deactivate Pull-down
Activate Pull-down and
deactivate Pull-up (2)
Activate Pull-down and deactivate Pull-up
Deactivate Pull-up and
Pull-down (3)
Deactivate Pull-up and Pull-down
u
SD/MMC Card Detect Internal Chip Pull-up/Pull-down Override
Configure
Description:
Configure SD/MMC Card Detect internal Chip Pull-up/Pull-down Override.
Disable (0) Disable override
Activate Pull-up and
deactivate Pull-down (1)
Activate Pull-up and deactivate Pull-down
Activate Pull-down and
deactivate Pull-up (2)
Activate Pull-down and deactivate Pull-up
Deactivate Pull-up and
Pull-down (3)
Deactivate Pull-up and Pull-down
