Brother HL-5350DN

5-44
Confidential
(4) Turn the Inner chute upside down.
(5) Remove the Pinch roller holder from the Inner chute.
Fig. 5-47
Assembling Note:
• When assembling the Pinch roller holder, be sure that its direction is correct as shown in
the figure above.
Inner chute
Pinch roller holder
Pinch roller holder
