3-3
Confidential
3 SCREW CATALOGUE
TAPTITE CUP B
TAPTITE BIND B
M4x12
SCREW BIND
TAPTITE CUP B
TAPTITE CUP B
M3x10
SCREW BIND
M3x6
M3x8
TAPTITE BIND B
M4x8
TAPTITE BIND B
M3x10
TAPTITE BIND B
TAPTITE CUP B
M4x12
SCREW CUP
SCREW CUP
M3x6
SCREW BIND
M2x12
SCREW PAN (S/P WASHER)
SCREW PAN
(S/P WASHER)
M3.5x6
SCREW PAN
(S/P WASHER)
M3x6
TAPTITE CUP B
M2.6x10
TAPTITE CUP B
M3x12
TAPTITE CUP S
TAPTITE CUP S
M3x6
