Brother MFC-J2330DW Service Manual

3-4
Confidential
4 SCREW TORQUE LIST
Location of screw Screw type Q’ty
Tightening
N•m (kgf•cm)
MP tray ASSY TAPTITE CUP B M4x12 2 0.70±0.10 (7±1)
FB FG wire SCREW BIND M3x6 1 0.35±0.05 (3.5±0.5)
ADF FG wire
Document scanner unit TAPTITE BIND B M4x12 2 0.70±0.10 (7±1)
ADF unit TAPTITE BIND B M4x8 2 0.80±0.10 (8±1)
ADF front cover TAPTITE CUP B M3x10 3 0.45±0.05 (4.5±0.5)
ADF separation pad holder ASSY TAPTITE CUP B M3x10 1 0.50±0.05 (5±0.5)
ADF unit TAPTITE CUP B M3x10 2 0.45±0.05 (4.5±0.5)
TAPTITE CUP B M2.6x10 3 0.30±0.05 (3±0.5)
Document cover top ASSY TAPTITE CUP B M3x10 4 0.50±0.05 (5±0.5)
TAPTITE CUP B M3x12 2 0.50±0.05 (5±0.5)
Document cover base TAPTITE BIND B M3x10 4 0.40±0.05 (4±0.5)
ADF hinge TAPTITE CUP B M3x10 2 0.50±0.05 (5±0.5)
Exit support plate TAPTITE CUP B M3x10 1 0.45±0.05 (4.5±0.5)
Lower doc chute ASSY TAPTITE CUP B M3x10 2 0.40±0.05 (4±0.5)
Document scanner unit TAPTITE CUP B M2.6x10 5 0.30±0.05 (3±0.5)
Document cover sensor TAPTITE CUP B M3x10 1 0.45±0.05 (4.5±0.5)
Front cover L TAPTITE BIND B M4x12 1 0.60±0.05 (6±0.5)
Upper cover TAPTITE BIND B M4x12 5 0.60±0.05 (6±0.5)
Main PCB harness hold TAPTITE CUP B M3x10 2 0.35±0.05 (3.5±0.5)
FG wire SCREW CUP M3x6 1 0.35±0.05 (3.5±0.5)
Tilt cover TAPTITE CUP B M3x10 2 0.35±0.05 (3.5±0.5)
Tilt hook TAPTITE CUP B M3x8 2 0.35±0.05 (3.5±0.5)
Panel lower cover TAPTITE CUP B M2.6x10 3 0.30±0.05 (3.0±0.5)
Main PCB shield SCREW CUP M3x6 2 0.35±0.05 (3.5±0.5)
Tray FG wire (T1) SCREW BIND M3x6 1 0.35±0.05 (3.5±0.5)
Tray FG wire (LT) SCREW BIND M3x6 1 0.35±0.05 (3.5±0.5)
Main PCB SCREW CUP M3x6 2 0.35±0.05 (3.5±0.5)
Upper modem frame SCREW CUP M3x6 1 0.35±0.05 (3.5±0.5)
Modem PCB SCREW CUP M3x6 1 0.35±0.05 (3.5±0.5)
Main PCB frame SCREW CUP M3x6 3 0.35±0.05 (3.5±0.5)
TAPTITE CUP B M3x10 2 0.35±0.05 (3.5±0.5)
Ink absorber box (with LT)
TAPTITE CUP B M3x10
2 0.50±0.05 (5±0.5)
Ink absorber box (without LT) 3 0.35±0.05 (3.5±0.5)
Tube support plate TAPTITE CUP B M3x10 2 0.35±0.05 (3.5±0.5)
Main PCB earth frame L TAPTITE CUP B M3x10 1 0.35±0.05 (3.5±0.5)
Main PCB earth frame TAPTITE CUP B M3x10 1 0.35±0.05 (3.5±0.5)
Ink ABS upper box ASSY TAPTITE CUP B M3x10 2 0.35±0.05 (3.5±0.5)

Brother MFC-J2330DW Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Scan Resolution	1200 x 2400 dpi
Fax Speed	33.6 kbps
Max Print Resolution	4800 x 1200 dpi
Print Speed (Black)	22 ppm
Print Speed (Color)	20 ppm
Duplex Printing	Automatic
Display	2.7" Touchscreen
ADF Capacity	50 sheets
Supported Paper Sizes	A3, A4
Operating System Support	Windows, macOS, Linux
Scanner Type	Flatbed, ADF
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Ink Cartridges	Black, Cyan, Magenta, Yellow
Paper Input Capacity	250 sheets
