Brother MFC-J2330DW Service Manual

3-5
Confidential
Location of screw Screw type Q’ty
Tightening
N•m (kgf•cm)
Main PCB earth frame R2 SCREW CUP M3x6 2 0.35±0.05 (3.5±0.5)
Switchback frame ASSY SCREW BIND M3x6 2 0.70±0.10 (7±1)
Lower side cover TAPTITE CUP B M3x10 2 0.35±0.05 (3.5±0.5)
CR frame ASSY TAPTITE CUP B M3x10 3 0.55±0.05 (5.5±0.5)
TAPTITE CUP S M3x6 1 0.65±0.10 (6.5±1)
Motor plate SCREW BIND M3x6 2 0.75±0.10 (7.5±1)
Carriage motor SCREW BIND M3x6 2 0.75±0.10 (7.5±1)
Lower tray unit TAPTITE BIND B M4x12 4 0.70±0.10 (7±1)
LT frame ASSY TAPTITE CUP B M3x10 3 0.50±0.05 (5±0.5)
Idle gear holder frame LT ASSY SCREW CUP M3x6 1 0.60±0.10 (6±1)
Bank chute LT TAPTITE BIND B M3x10 2 0.50±0.05 (5±0.5)
Power supply PCB ASSY SCREW CUP M3x6 3 0.40±0.10 (4±1)
Power supply unit TAPTITE CUP B M3x10 1 0.35±0.05 (3.5±0.5)
AC cord FG wire (Case of 200V)
SCREW PAN (S/P WASHER)
M3.5x6
1 0.45±0.05 (4.5±0.5)
Encoder cover SCREW BIND M3x6 2 0.60±0.10 (6±1)
Encoder sensor holder SCREW BIND M2x12 2 0.15±0.05 (1.5±0.5)
CR guide rail SCREW BIND M3x6 2 0.60±0.10 (6±1)
TAPTITE CUP B M3x10 2 0.55±0.05 (5.5±0.5)
Paper feed motor plate
SCREW PAN (S/P WASHER)
M3x6
1 0.30±0.10 (3±1)
SCREW PAN (S/P WASHER)
M3x6
(Screws to be tightened after
the PF roller belt is mounted.)
1 0.60±0.10 (6±1)
Maintenance unit TAPTITE CUP B M3x10 1 0.35±0.05 (3.5±0.5)
SCREW BIND M3x6 2 0.60±0.10 (6±1)
Frame base ASSY TAPTITE CUP B M3x10 4 0.35±0.05 (3.5±0.5)
Flushing box TAPTITE CUP B M3x10 2 0.35±0.05 (3.5±0.5)
Paper feed arm frame ASSY TAPTITE CUP B M3x10 2 0.35±0.05 (3.5±0.5)
Tray FG wire (T1) TAPTITE CUP B M3x10 1 0.35±0.05 (3.5±0.5)
Lower cover frame TAPTITE CUP B M3x10 3 0.35±0.05 (3.5±0.5)
