Brother MFC-J2330DW Service Manual

1-5
Confidential
1.3 Paper Handling
1.4 LCD Panel
1.5 Memory
Model
MFC-J2330DW MFC-J2730DW MFC-J5330DW MFC-J5335DW
Paper Input
(sheets)
Standard Tray 250 (80 g/m
2
)
Lower Tray N/A 250 (80 g/m
2
) N/A
Manual Feed Slot
1 (Plain: 120 g/m
2
Glossy:
thickness 0.25 mm)
N/A
1 (Plain: 120 g/m
2
Glossy:
thickness 0.25 mm)
MP Tray
N/A 100 (80 g/m
2
) N/A
ADF
50 (80 g/m
2
)
(face up)
*sort copy up to 30
50 (80 g/m
2
)
(face up)
50 (80 g/m
2
)
(face up)
*sort copy up to 30
Output Paper Capacity
(sheets)
100 (Up to A4/LTR) 50 (Over A4/LTR) (80 g/m
2
)
Auto Paper Low Detection
N/A
Document Scan Size Sensor N/A
Model
MFC-J5730DW MFC-J5830DW MFC-J5930DW
Paper Input
(sheets)
Standard Tray 250 (80 g/m
2
)
Lower Tray 250 (80 g/m
2
) N/A 250 (80 g/m
2
)
Manual Feed Slot N/A
MP Tray 100 (80 g/m
2
)
ADF
50 (80 g/m
2
)
(face up)
50 (80 g/m
2
)
(face up)
*sort copy up to 30)
50 (80 g/m
2
)
(face up)
Output Paper Capacity
(sheets)
100 (Up to A4/LTR) 50 (Over A4/LTR) (80 g/m
2
)
Auto Paper Low Detection
N/A
Standard Tray /
Lower Tray
Document Scan Size Sensor
N/A
Model MFC-J2330DW/J5330DW/J5335DW MFC-J2730DW/J5730DW/J5830DW/J5930DW
LCD
Type & Size 2.7 inch TFT 3.7 inch TFT
Touch-Panel Yes
Model
MFC-J2330DW/J5330DW/J5335DW/
J5830DW
MFC-J2730DW/J5730DW MFC-J5930DW
Memory Capacity
(physical: Mbytes)
128 MB 256 MB 512 MB
Memory Backup
(with Flash memory)
Yes

Brother MFC-J2330DW Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Scan Resolution	1200 x 2400 dpi
Fax Speed	33.6 kbps
Max Print Resolution	4800 x 1200 dpi
Print Speed (Black)	22 ppm
Print Speed (Color)	20 ppm
Duplex Printing	Automatic
Display	2.7" Touchscreen
ADF Capacity	50 sheets
Supported Paper Sizes	A3, A4
Operating System Support	Windows, macOS, Linux
Scanner Type	Flatbed, ADF
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Ink Cartridges	Black, Cyan, Magenta, Yellow
Paper Input Capacity	250 sheets
