Model MFC-J5730DW MFC-J5830DW MFC-J5930DW
Media
Sizes
Standard Tray
<Landscape> A4, LTR, EXE, B5 (JIS)
*1
<Portrait> A3, LGR, LGL, Folio, B4 (JIS)
*1
, A5, B6 (JIS)
*1
, A6, Photo (10 x 15cm/4 x 6"), Index
card (13 x 20cm/5 x 8"), Photo-L (9 x 13cm/3.5 x 5"), Photo-2L (13 x 18cm/5 x 7"), Com-10, DL
Envelope, Monarch, C5, Mexico Legal, India Legal
* Photo paper is available up to A4/LTR.
Lower Tray
<Landscape> A4, LTR
<Portrait> A3, LGR, B4 (JIS)
*1
,
LGL, Folio, Mexico Legal, India
Legal
N/A
<Landscape> A4, LTR
<Portrait> A3, LGR, LGL,
Folio, Mexico Legal, India
Legal
Manual Feed Slot
N/A
MP Tray
<Landscape> A4, LTR, EXE, B5 (JIS)
*1
<Portrait> A3, LGR, B4 (JIS)
*1
, LGL, Folio, A5, B6 (JIS)
*1
, A6, Photo (10 x 15cm/4 x 6"), Index
card (13 x 20cm/5 x 8"), Photo-L (9 x 13cm/3.5 x 5"), Photo-2L (13 x 18cm/5 x 7"), Com-10, DL
Envelope, Monarch, C5, Mexico Legal, India Legal
Duplex Print
<PC Print> A4, LTR, EXE, A5, B5 (JIS)
*1
, B6 (JIS)
*1
<Copy> A4, LTR, EXE
*3
, A5
ADF (width/length) 105/148 mm to 215.9/355.6 mm (4.1/5.8" to 8.5/14.0") * long paper length: 900mm(35.4")
Scanner Glass
(width/length)
up to 215.9/297 mm (up to 8.5/11.7")
Media
Weights
Standard Tray 64-220 g/m
2
(17-58 lb.)
Lower Tray 64-120 g/m
2
(17-32 lb.) N/A 64-120 g/m
2
(17-32 lb.)
Manual Feed Slot N/A
MP Tray 64-220 g/m
2
(17-58 lb.)
Duplex Print 64-120 g/m
2
(17-32 lb.)
ADF 64-90 g/m
2
(17-24 lb.)
Media
Types
Standard Tray Plain, Inkjet, Glossy, Recycled * Glossy is available up to A4/LTR.
Lower Tray Plain, Recycled
N/A Plain, Recycled
Manual Feed Slot N/A
MP Tray Plain, Inkjet, Glossy, Recycled
Duplex Print Plain, Recycled
ADF Plain, Recycled
