Brother MFC-J2330DW Service Manual

1-2
Confidential
1.2 Media Specification
*1
Only for Hong Kong/Taiwan/China
*2
Only for China
*3
Only for U.S.A.
Model MFC-J2330DW MFC-J2730DW MFC-J5330DW MFC-J5335DW
Media
Sizes
Standard Tray
<Landscape> A4, LTR, EXE, B5 (JIS)
*1
<Portrait> A3, LGR, LGL, Folio, B4 (JIS)
*1
, A5, B6 (JIS)
*1
, A6, Photo (10 x 15 cm/4 x 6"), Index
card (13 x 20 cm/5 x 8"), Photo-L (9 x 13 cm/3.5 x 5"), Photo-2L (13 x 18 cm/5 x 7"), Com-10,
DL Envelope, Monarch, C5, Mexico Legal, India Legal, 16K (195 x 270 mm)
*2
* Photo paper is available up to A4/LTR.
Lower Tray
N/A
<Landscape> A4, LTR
<Portrait> A3, LGR,
B4 (JIS)
*1
, LGL, Folio,
Mexico Legal, India
Legal
N/A
Manual Feed Slot
<Landscape> A4,
LTR, EXE, B5 (JIS)
*1
<Portrait> A3, B4
(JIS)
*1
, LGR, LGL,
Folio, A5, B6 (JIS)
*1
,
A6, Photo (10 x 15 cm/
4 x 6"), Index card (13
x 20 cm/5 x 8"), Photo-
L (9 x 13 cm/3.5 x 5"),
Photo-2L (13 x 18 cm/
5 x 7"), C5, Com-10,
DL Envelope,
Monarch, Mexico
Legal, India Legal,16K
(195 x 270 mm)
*2
N/A
<Landscape> A4, LTR, EXE, B5 (JIS)
*1
<Portrait> A3, B4 (JIS)
*1
, LGR, LGL, Folio, A5,
B6 (JIS)
*1
, A6, Photo (10 x 15 cm/4 x 6"), Index
card (13 x 20 cm/5 x 8"), Photo-L (9 x 13 cm/
3.5 x 5"), Photo-2L (13 x 18 cm/5x7"), C5,
Com-10, DL Envelope, Monarch, Mexico
Legal, India Legal
MP Tray
N/A
<Landscape> A4,
LTR, EXE, B5 (JIS)
*1
<Portrait> A3, LGR,
B4 (JIS)
*1
, LGL, Folio,
A5, B6 (JIS)
*1
, A6,
Photo (10 x 15 cm/4 x
6"), Index card (13 x
20 cm/5 x 8"), Photo-L
(9 x 13 cm/3.5 x 5"),
Photo-2L(13 x 18 cm/5
x 7"), Com-10, DL
Envelope, Monarch,
C5, Mexico Legal,
India Legal, 16K (195
x 270 mm)
*2
N/A
Duplex Print
<PC Print> A4, LTR, EXE, A5, B5 (JIS)
*1
, B6 (JIS)
*1
, 16K (195 x 270 mm)
*2
<Copy> A4, LTR, EXE
*3
, A5
ADF (width/length) 105/148 mm to 215.9/355.6 mm (4.1/5.8" to 8.5/14.0") * long paper length: 900mm(35.4")
Scanner Glass
(width/length)
up to 215.9/297 mm (up to 8.5/11.7")

Brother MFC-J2330DW Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Scan Resolution	1200 x 2400 dpi
Fax Speed	33.6 kbps
Max Print Resolution	4800 x 1200 dpi
Print Speed (Black)	22 ppm
Print Speed (Color)	20 ppm
Duplex Printing	Automatic
Display	2.7" Touchscreen
ADF Capacity	50 sheets
Supported Paper Sizes	A3, A4
Operating System Support	Windows, macOS, Linux
Scanner Type	Flatbed, ADF
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Ink Cartridges	Black, Cyan, Magenta, Yellow
Paper Input Capacity	250 sheets
