Brother MFC-J2330DW Service Manual

3-63
Confidential
9.22 Ink Cartridge Cover
(1) Open the Ink cartridge cover.
(2) Release the two Pins and remove the Ink cartridge cover from the Main body.
Note: When replacing the Ink cartridge cover, be sure to remove the serial number
label attached inside the old cover and attach it to the new cover.
Fig. 3-55
Ink cartridge cover
Main body
Pins
1
2

Brother MFC-J2330DW Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Scan Resolution	1200 x 2400 dpi
Fax Speed	33.6 kbps
Max Print Resolution	4800 x 1200 dpi
Print Speed (Black)	22 ppm
Print Speed (Color)	20 ppm
Duplex Printing	Automatic
Display	2.7" Touchscreen
ADF Capacity	50 sheets
Supported Paper Sizes	A3, A4
Operating System Support	Windows, macOS, Linux
Scanner Type	Flatbed, ADF
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Ink Cartridges	Black, Cyan, Magenta, Yellow
Paper Input Capacity	250 sheets
