Brother MFC-J2330DW Service Manual

5-65
Confidential
AMS01 (Printing assurance 1)
- Selector 1: Prevention of stains on back side of leading edge of paper in
borderless printing
Setting this selector to "1" reduces the protruding amount of the leading edge of
recording paper to the platen groove to minimize stains that could be caused by
ink mist on the back side of the leading edge. Enabling this function reduces the
throughput than disabling it.
Selector
No.
Function Setting and Specifications
1
Prevention of stains on back side
of leading edge of paper in
borderless printing
0: Disable (default) 1: Enable
2 Not used.
3
4
Protection of platen from no-
paper printing to prevent stains
(Functional restriction on the
paper width sensor)
No. 3 4
0 0 : Determine the sensor function
depending upon the print
resolution selected (default)
0 1 : Detect the leading edge plus right
and left edges of paper
1 0 : Detect the leading edge of paper
1 1 : No paper detection
5
Assurance print 1
(Printing with black, cyan inks in
monochrome copy)
0: Disable (default) 1: Enable
6
Assurance print 2
(Printing with black, cyan inks in
monochrome FAX reception and
in list output)
0: Disable (default) 1: Enable
7
8
Workaround for false jam
detection
(Functional restriction on the
paper width sensor)
No. 7 8
0 0 : Detect both the leading edge and
width of paper (default)
0 1 : Detect both the leading edge and
width of paper
1 0 : Detect only the leading edge of
paper
1 1 : No detection

Brother MFC-J2330DW Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Scan Resolution	1200 x 2400 dpi
Fax Speed	33.6 kbps
Max Print Resolution	4800 x 1200 dpi
Print Speed (Black)	22 ppm
Print Speed (Color)	20 ppm
Duplex Printing	Automatic
Display	2.7" Touchscreen
ADF Capacity	50 sheets
Supported Paper Sizes	A3, A4
Operating System Support	Windows, macOS, Linux
Scanner Type	Flatbed, ADF
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Ink Cartridges	Black, Cyan, Magenta, Yellow
Paper Input Capacity	250 sheets
