Brother MFC-J2330DW Service Manual

Confidential
2-39
■ Error Code 6701
T2 detection sensor detects no paper tray #2 state.
< User Check >
- Set paper tray #2.
■ Error Code 6F00
ASF motor cannot stop.
Error Code 6F01
ASF encoder sensor cannot detect rotation of the ASF motor
.
Step Cause Solution
1 T2 detection actuator caught
on the surrounding parts
Set the T2 detection actuator into place.
2 T2 detection sensor harness
connection failure
Reconnect the T2 detection sensor harness.
3 Paper tray #2 defective Replace the paper tray ASSY #2.
4 Main PCB defective Replace the main PCB.
Step Cause Solution
1 ASF encoder sensor harness
connection failure
Reconnect the ASF encoder sensor harness.
2 ASF motor harness connection
failure
Reconnect the ASF motor harness.
3 Maintenance unit defective Replace the maintenance unit.
4 Main PCB defective Replace the main PCB.

Brother MFC-J2330DW Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Scan Resolution	1200 x 2400 dpi
Fax Speed	33.6 kbps
Max Print Resolution	4800 x 1200 dpi
Print Speed (Black)	22 ppm
Print Speed (Color)	20 ppm
Duplex Printing	Automatic
Display	2.7" Touchscreen
ADF Capacity	50 sheets
Supported Paper Sizes	A3, A4
Operating System Support	Windows, macOS, Linux
Scanner Type	Flatbed, ADF
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Ink Cartridges	Black, Cyan, Magenta, Yellow
Paper Input Capacity	250 sheets
