Brother MFC-J2330DW Service Manual

Confidential
2-43
< User Check >
- Check that the recording paper of the specified size is used.
- Check that recording paper is loaded in correct direction in the paper tray.
- Check that dark recording paper is not used.
-
Clean the platen.
Step Cause Solution
1 Registration actuator caught
on the surrounding parts
Set the registration actuator into place.
2 CR encoder strip stained Clean the CR encoder strip.
3 PF encoder disk stained Clean the PF encoder disk and flushing guide.
(refer to "Precautions for Troubleshooting and/
or Disassembly/Assembly")
4 CR encoder strip defective Replace the CR encoder strip.
5
PF encoder disk defective Replace the PF encoder disk.
6 Paper width sensor defective Replace the carriage PCB ASSY.
7
PF encoder sensor defective Replace the PF encoder sensor PCB.
8 Registration sensor defective Replace the registration sensor PCB.
9 Carriage motor defective Replace the carriage motor.
10 Paper feed motor defective Replace the paper feed motor.
11 Maintenance unit defective Replace the maintenance unit.
12 Main PCB defective Replace the main PCB.

Brother MFC-J2330DW Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Scan Resolution	1200 x 2400 dpi
Fax Speed	33.6 kbps
Max Print Resolution	4800 x 1200 dpi
Print Speed (Black)	22 ppm
Print Speed (Color)	20 ppm
Duplex Printing	Automatic
Display	2.7" Touchscreen
ADF Capacity	50 sheets
Supported Paper Sizes	A3, A4
Operating System Support	Windows, macOS, Linux
Scanner Type	Flatbed, ADF
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Ink Cartridges	Black, Cyan, Magenta, Yellow
Paper Input Capacity	250 sheets
