III - 51
(7) Pass the link lever through the hole of the upper cover, and then hang the hooks
on the under cover to set the upper cover onto the under cover.
(8) Secure the upper cover with the two screws A and the five screws B.
NOTE: The screws A are screw, bind M2.6x4. The screws B are taptite, bind B
M2.6x8.
Fig. 3.5-34 Reassembling the Upper Cover and the Under Cover (6)
Under cover
Hook
Screws B
Screws B
Screws A
Hook
Upper cover
Upper cover
Hole
Link lever

Brother P-touch QL-710W Specifications

General

Maximum Label Width	62 mm
Resolution	300 dpi
Cutter	Automatic
Device Category	Label Maker
Power Source	AC adapter
Printing Technology	Thermal
Connectivity	USB, Wi-Fi
Media Type	Die-cut labels, Continuous labels
Supported OS	Windows, Mac
