III - 2
3.2 TIGHTNING TORQUE LISTS
Location Screw type Q'ty
Tightening torque
N
·cm
Top cover ASSY Taptite, bind B M2.6x8 2 0.343
± 0.049
Lower plate ASSY Taptite, bind B M2.6x8 4 0.343
± 0.049
Panel cover Taptite, bind B M2.6x8 2 0.343
± 0.049
SB PCB ASSY Taptite, bind B M2.6x8 2 0.343
± 0.049
Upper cover
Screw, bind M2.6x4 2 0.392
± 0.098
Taptite, bind B M2.6x8 5 0.343
± 0.049
Insert guide Taptite, bind B M2.6x8 2 0.343
± 0.049
Back cover Taptite, bind B M2.6x8 3 0.343
± 0.049
Power supply ASSY Taptite, bind B M2.6x8 2 0.343
± 0.049
Ground spring plate Taptite, bind B M2.6x8 1 0.343
± 0.049
FG harness ASSY Taptite, bind B M2.6x8 1 0.343
± 0.049
Main PCB ASSY Taptite, bind B M2.6x8 1 0.343
± 0.049
Media PCB ASSY Taptite, bind B M2.6x8 2 0.343
± 0.049
Mecha ASSY Taptite, bind B M2.6x8 2 0.343
± 0.049
Cutter unit ASSY Screw, bind M2.6x5 2 0.392
± 0.098
Platen shaft bushing Screw, bind M2x4 2 0.098
± 0.049
FG harness ASSY Screw, bind M3x4 1 0.588
± 0.098
Tape feed motor ASSY Screw, bind M3x4 1 0.588
± 0.098
