S-7300A
6. ASSEMBLY
99
5. Face plate
6. Screws [4 pcs]
1005D
7. Screws [2pcs] (Fully tighten)
1006D
Install so that the arm and the face plate are correctly
aligned.
Place the cushion (a) of the hand switch 1 against the arm (b),
and then fully tighten the screw 7.
