S-7300A
11. TROUBLESHOOTING
181
11-2. List of error codes
If an error code appears on the touch panel display
・ Items with a "*" in the "Page" column should only be checked by a qualified technician.
・ For items with "**" appearing in the "Page" column, ask the place of purchase for advice.
<Connector layout diagram>
Main P.C. board
0927D
Connector P1
Connector P2
Connector P3
Connector P4
Connector P5
Power supply connector
Feed motor connector
Sewing machine motor connector
Connector P13
Connector P6
0926D
