S-7300A
6. ASSEMBLY
102
6-17-2. Harnesses
1114D
1. Cord holder
2. Screw
3. Cord holder
4. Screw
5. Cord holder
6. Screw
Bind the panel and main shaft motor harnesses
together also.
Bind the harnesses of the feed motor and the thread
trimmer solenoid together.
1113D
