Brother S-7300A - ELECTRIC MECHANISM

S-7300A
8. REPLACING PARTS
156
5. Remove the nut (4) and wire holder D (5), and then
remove the tension release wire (6).
6. Remove the tubes (8) from the three tube bands (7).
7. Remove the screw (10) of the motor cover (9).
8. Loosen the two set screws (12) of the PM arm (11).
0973D
0974D
0975D
