Brother S-7300A - Page 47

S-7300A
3. FUNCTION SETTINGS
36
When updating the panel control program version
1
<Preparation for updating the program version>
1. The panel control program (ISM20PL.upf) can be found in the following folder in the USB media.
¥BROTHER¥ISM¥ISMSYS¥
2. Connect the card reader which has the USB media inserted to the USB port.
2
<Starting software version update mode>
1. While pressing the half stitch key, turn on the power to switch to the version
update selection screen.
3
<Version update selection mode>
1. Check that the version number (1) for the panel control program that you
are going to update is correct.
2. Press the lower Update key (2) to start the version update.
4
<While version updates are running>
1. While version updating is in progress, the progress status will be displayed.
* Do not turn off the power while version updating is in progress.
2. Once version updating is finished, turn off the power.
(2)
(1)
