Communication Objects
4
ekr CON 600 net – Process Data Exchange via Profibus 39/79
4.1.2.12 EkrIn_Auto Sp Acp
Slot 12
Slot Name ADI_Data_12_1
Object EkrIn_Auto Sp Acp
Function Sensor positioner –
Activating the automatic setpoint take-over for the sensor positioner
If the Automatic setpoint take-over function is activated, after switching to Automatic
operating mode, the sensor positioner (e.g. FVGPOS100) carries out an automatic
edge detection. In doing so, the sensor slides run towards the web of material until the
sensors have detected a web edge. The position of the web edge detected is taken over
as the setpoint for guiding.
Data types Unsigned8
Access Write-only
Object length 2 bytes
Name Data Type Bit Meaning Data Description
Parameter
selection bit field
Unsigned8 0 Automatic setpoint take over
The following data
becomes valid if the
corresponding bit in this
parameter selection bit
field is set (see Using
the Parameter Selection
Bit Field, page 17).
Automatic
setpoint take over
Unsigned8
0
Activating/deactivating the automatic
setpoint take-over
Bit 0 must be activated
so that the guiding
mode dependent
automatic setpoint
take-over is taken into
account.
1
– Automatic setpoint take-over for
web edge guiding – Edge1
2
– Automatic setpoint take-over for
web edge guiding – Edge2
3
– Automatic setpoint take-over
for web center-line guiding – Center1&2
4 Reserved
5 Reserved
6 Reserved
7 Reserved
