BST ekr CON 600 net Translation Of The Original Manual

4
Communication Objects
38/79 ekr CON 600 net – Process Data Exchange via Profibus
4.1.2.11 EkrOut_Setpoint
Slot 11
Slot Name ADI_Data_11_1
Object EkrOut_Setpoint
Function Reading the setpoint values for the different guiding modes
Data types SInteger32
Access Read-only
Object length 20 bytes
Name Data Type Bit Meaning Data Description
Setpoint E1 SInteger32
– Web edge guiding – Setpoint edge1
Unit depending on the
sensor type used
Digital edge sensor: µm
Setpoint E2 SInteger32
– Web edge guiding – Setpoint edge2
Unit depending on the
sensor type used
Digital edge sensor: µm
Setpoint E3 SInteger32
– Line/contrast guiding – Setpoint edge3
Unit depending on the
sensor type used
CLSPro600: Pixel
Setpoint C12 SInteger32
– Web center-line guiding –
Setpoint center1&2
Unit depending on the
sensor type used
Digital edge sensor: µm
Setpoint SC SInteger32
– Operating mode Center positioning –
Setpoint center position
Unit depending on the
servo center transducer
used
