BST ekr CON 600 net Translation Of The Original Manual

4
Communication Objects
52/79 ekr CON 600 net – Process Data Exchange via Profibus
4.2.2.7 Guiding source base mode
Slot 2
Index 30
Object Guiding source base mode
Function Selecting the sensor type to be used for guiding
The sensor source for web guiding can be determined by the master.
Data types Unsigned8
Access Read & Write
Object length 2 byte
Name Data Type Bit Meaning Data Description
Parameter
selection bit
field
Unsigned8 0 Guid Src Base Mode
The following data becomes
valid if the bit0 in this para-
meter selection bit field is set.
Guid Src Base
Mode
Unsigned8
00h: Automatic selection of the sensor
by the controller
01h: Guiding with CCD camera
Type CCDPro or CCDCAM100
in compability mode
02h: Guiding with digital edge sensor Type US2010, IR2011, IR2012
03h: Guiding with analogue edge sensor Type RS…
04h: Guiding with sensor positioner Type FVGPOS100
05h: Guiding with digital CCD camera Type CCDCAM100
