BST ekr CON 600 net Translation Of The Original Manual

4
Communication Objects
60/79 ekr CON 600 net – Process Data Exchange via Profibus
4.2.2.19 ClsOut_JobInterface
Slot 2
Index 70
Object ClsOut_JobInterface
Function Reading the data from the setup administration of the CLSPro600 line and contrast
sensor
Data types Unsigned8, Unsigned32
Access Read-only
Object length 10 bytes
Name Data Type Bit Meaning Data Description
Little
Endian
Big
Endian
Sensor status Unsigned32
0 24
Controller needs
configuration
Bit 0 must be 0 to load or
save a setup slot.
1 25 Setup OK
Bit 1 must be 1. Only then is
the sensor in measuring
mode and valid characteristic
data in the memory.
2
…
7
26
…
31
Reserved
8
…
13
16
…
21
Reserved
14 22 Setup failed
If bit 14 is set, the activation
of the last setup has failed
(CRC error).
15 23 Reserved
16
…
23
8
…
15
Reserved
24
…
31
0
…
7
Reserved
Job Data Valid
Field
Unsigned32
0 24 Setup slot 1 is available
The bit is 1 if a setup is
stored under the index of the
bit position.
1 25 Setup slot 2 is available
2 26 Setup slot 3 is available
3 27 Setup slot 4 is available
4 28 Setup slot 5 is available
5 29 Setup slot 6 is available
6 30 Setup slot 7 is available
