BST ekr CON 600 net Translation Of The Original Manual

2
Design and Function
10/79 ekr CON 600 net – Process Data Exchange via Profibus
2.2.3 Status LEDs on the Profibus Interface Module
The Profibus interface module has six status LEDs indicating the
operating status of the network connection and the interface
module.
Status LEDs
Fig.5: Status LEDs on the Profibus interface module
Status LED Display Function Description
H1
Reserved
H11
H21
Module status See Module Status LEDs, page 11
H22
H23
Network status See Network Status LEDs, page 11
H24
The current operating status of the interface module and
of the network connection is also displayed via the virtual
status LEDs in the operating display of the ekrCON600net
controller (see Status LEDs in the Operating Display of
the Controller, page 12).
