BST ekr CON 600 net Translation Of The Original Manual

4
Communication Objects
48/79 ekr CON 600 net – Process Data Exchange via Profibus
4.2.2.3 Material Setup SEN
Slot 2
Index 24
Name Material Setup SEN
Function Performing a material setup for a connected edge sensor
During the material setup the controller is automatically adjusted to the properties of
the material to be scanned.
Data types Unsigned8, Unsigned16
Access Read & Write
Object length 10 bytes
Name Data Type Bit Meaning Data Description
Parameter selection
bit field
Unsigned8
0 SEN1 (edge sensor1)
The following data becomes
valid if the corresponding bit in
this parameter selection bit field
is set (see Using the Parameter
Selection Bit Field, page 17).
1 SEN2 (edge sensor2)
2 SEN3 (edge sensor3)
3 SEN4 (edge sensor4)
4 Reserved
5 Reserved
6 Reserved
7 Reserved
Padding byte Unsigned8 Padding byte Unusable
SEN1 Unsigned16
01h: Start Auto-Setup
Automatic material setup:
Starting the material setup
02h: Start bright value
Manual material setup:
Starting the recording of the
bright value
03h: Start dark value
Manual material setup:
Starting the recording of the
dark value
04h: End Auto-Setup
Automatic material setup:
Ending the material setup
05h: End bright value
Manual material setup:
Saving the recorded bright value
06h: End dark value
Manual material setup:
Saving the recorded dark value
SEN2 Unsigned16
See description under SEN1SEN3 Unsigned16
SEN4 Unsigned16
