Communication Objects
40/79 ekr CON 600 net – Process Data Exchange via Profibus
4.1.2.13 EkrOut_Auto Sp Acp
Slot 13
Slot Name ADI_Data_13_1
Object EkrOut_Auto Sp Acp
Function Sensor positioner –
Reading the operating status of the automatic setpoint take-over
Data types Unsigned8
Access Read-only
Object length 1 byte
Name Data Type Bit Meaning Data Description
Automatic
setpoint take over
Unsigned8
0
Activating/deactivating of the automatic
setpoint take-over
Bit 0 must be activated
so that the guiding
mode dependent
automatic setpoint
take-over is taken into
account.
1
– Automatic setpoint take-over for
web edge guiding – Edge1
2
– Automatic setpoint take-over for
web edge guiding – Edge2
3
– Automatic setpoint take-over
for web center-line guiding – Center1&2
4 Reserved
5 Reserved
6 Reserved
7 Reserved
