BST ekr CON 600 net Translation Of The Original Manual

Communication Objects
4
ekr CON 600 net – Process Data Exchange via Profibus 47/79
4.2.2.2 Oscillation
Slot 1
Index 245
Object Oscillation
Function Specifying basic settings for the material web oscillation
The related values can be changed at any time. However, an initialization takes place,
which can cause an offset depending on the current position of the amplitude.
Data types Unsigned8, Unsigned16, Unsigned32
Access Read & Write
Object length 14 bytes
Name Data Type Bit Meaning Data Description
Parameter selection
bit field
Unsigned8
0 Oscillation mode
The following
data becomes
valid if the
corresponding bit
in this parameter
selection bit field
is set (see Using
the Parameter
Selection Bit
Field, page 17).
1 Osc freqcy
2 Osc ampl
3 Osc SC freqcy
4 Osc SC ampl
5 Reserved
6 Reserved
7 Reserved
Oscillation form Unsigned8
0: Triangular curve
1: Sinus curve
Osc freqcy Unsigned16 Frequency for the material web oscillation Unit: 1/min
Osc ampl Unsigned32 Amplitude for the material web oscillation Unit: µm
Osc SC freqcy Unsigned16
Frequency for the material web oscillation in
operating mode Center Positioning
Unit: 1/min
Osc SC ampl Unsigned32
Amplitude for the material web oscillation in
operating mode Center Positioning
Unit: µm
