BST ekr CON 600 net Translation Of The Original Manual

Communication Objects
4
ekr CON 600 net – Process Data Exchange via Profibus 55/79
4.2.2.10 Params SEN 1
Slot 2
Index 39
Object Params SEN 1
Function Reading the sensor parameters for the connected edge sensor1
Data types Unsigned8, Unsigned16, SInteger32
Access Read-only
Object length 32 bytes
Name Data Type Meaning Data Description
Offset SInteger32
Offset value for the output of
the measured values
Unit depending on the sensor type used
Digital edge sensor: µm
Example: Edge sensor IR2011,
measuring range 24mm (±12mm)
=> Offset = -12,000
Upper limit SInteger32
Upper limit value
The highest measured value
that the connected sensor can
output.
Unit depending on the sensor type used
Digital edge sensor: µm
Example: Edge sensor IR2011,
measuring range 24mm (±12mm)
=> Upper limit = 12,000
Lower limit SInteger32
Lower limit value
The lowest measured value that
the connected sensor can
output.
Unit depending on the sensor type used
Digital edge sensor: µm
Example: Edge sensor IR2011,
measuring range 24mm (±12mm)
=> Lower limit = -12,000
Setpt limit Min SInteger32
Setpoint lower limit
If this sensor is used for web
guiding, the setpoint can only be
changed up to this lower limit.
Unit depending on the sensor type used
Digital edge sensor: µm
Setpt limit Max SInteger32
Setpoint upper limit
If this sensor is used for web
guiding, the setpoint can only be
changed up to this upper limit.
Unit depending on the sensor type used
Digital edge sensor µm
Status Unsigned16 Reserved
Active Unsigned8
Sensor detection
1: Sensor detected
0: No sensor detected
Padding byte Unsigned8 Padding byte Unusable
