Communication Objects
56/79 ekr CON 600 net – Process Data Exchange via Profibus
Name Data Type Meaning Data Description
Val. range SInteger32 Sensor measuring range
Unit depending on the sensor type used
Digital edge sensor: µm
Example: Edge sensor IR2011,
measuring range 24mm (±12mm)
=> Val. range = 24,000
Device id Unsigned16
Device identification of the
sensor
Example:
The edge sensor IR2011 has the device
ID 81
d
or 51
h
.
Phys. unit Unsigned8 Reserved
Aux. offset Unsigned8 Reserved
4.2.2.11 Params SEN 2
Slot 2
Index 40
Object Params SEN 2
Function Reading the sensor parameters for the connected edge sensor2
Data types Unsigned8, Unsigned16, SInteger32
Access Read-only
Object length 32 bytes
A description of the various parameters can be found in chapter
Params SEN 1, page 55.
4.2.2.12 Params SEN 3
Slot 2
Index 41
Object Params SEN 3
Function Reading the sensor parameters for the connected edge sensor3
Data types Unsigned8, Unsigned16, SInteger32
Access Read-only
Object length 32 bytes
A description of the various parameters can be found in chapter
Params SEN 1, page 55.
