Burstner Premio - Swivel Toilet

149Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Sanitary fittings
10
10.8.2 Swivel toilet
The flushing of the Thetford toilet is fed directly from the water system of the
vehicle. The toilet bowl can be moved into the optimal position.
The operating unit is located close to the toilet bowl.
Flushing:
 Before flushing open the sliding trap of the Thetford toilet. To do this, push
the slide lever (Fig. 191,1 or Fig. 192,1) in an anticlockwise direction.
 For flushing, press the blue flush button (Fig. 193,1 or Fig. 194,1).
 After flushing close the sliding trap. To do this push the slide lever in a
clockwise direction.
The indicator lamp (Fig. 193,2 or Fig. 194,2) lights up whenever the sewage
tank has to be emptied.
Fig. 191 Thetford toilet bowl, swivelling Fig. 192 Thetford toilet bowl, swivelling
(alternative)
Fig. 193 Flush button/indicator lamp
Thetford toilet
Fig. 194 Flush button/indicator lamp
Thetford toilet (alternative)
