151Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Sanitary fittings
10
10.8.4 Emptying the sewage tank
Slide the slide lever on the toilet bowl in a clockwise direction. The sliding
trap is closed.
Open the flap for the sewage tank on the outside of the vehicle. Insert the
key into the locking cylinder of the push-button lock (Fig. 197,1) and turn a
quarter turn in a clockwise direction.
Remove the key.
Press both push-button locks (Fig. 197,2) simultaneously with your thumb
and open the flap for the sewage tank.
Pull the retaining clip (Fig. 198,1) upwards and pull out the sewage tank
(Fig. 198,2).
Completely empty the sewage tank at disposal stations that are especially
provided for this purpose.
Z The sewage tank can only be taken out if the sliding trap is closed.
Fig. 197 Flap for the sewage tank Fig. 198 Sewage tank
Z Actuate the aeration knob on the sewage tank with your thumb to empty it
completely.
