30 Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Before the journey
3
Loading the bicycles: Put the bikes on to the bike rack (Fig. 13,2) and secure them with quick
straps (Fig. 13,1).
Bike rack on the rear wall Depending on the model, the bike rack is either screwed directly onto the rear
wall or clipped into special brackets at the rear. Beneath the vehicle the bike
rack is screwed to the floor plate.
Loading the bicycles:
Put the bikes onto the bike rack and secure them with quick straps.
In addition, secure each bicycle on the retaining bracket or retaining arm.
3.9 External mirrors
Fig. 13 Front bike rack
Fig. 14 Bike rack on the rear wall
X Before every journey, re-adjust the external mirrors on the towing
vehicle for safety reasons.
Z Additional mirrors must be EC-type certified and thus meet the EC guide-
lines.
