Living
6
Blind The blind is located in the bottom blind box.
Closing:
 Press handle (Fig. 68,4) and draw blind (Fig. 68,3) from the bottom to the
top up to the desired height.
 Release handle. The blind locks into the nearest locking position.
Opening:
 Clench handle (Fig. 68,4). The latch is released.
 Slowly return the blind (Fig. 68,3) to its initial position.
Insect screen The insect screen is located in the upper blind box.
Closing:
 Pull insect screen (Fig. 68,2) down until it touches the blind (Fig. 68,3), and
engage the closure latch (Fig. 68,1) in the locking device (Fig. 68,5).
Opening:
 Release the closure latch (Fig. 68,1).
 Slowly return insect screen into its initial position.
6.10.5 Roman shade and insect screen
The windows are fitted with a Roman shade and an insect screen. Roman
shade and insect screen are fixed to each other.
Roman shade The Roman shade is located in the upper window frame.
Closing:
 Hold the Roman shade in the centre of the bottom rod (Fig. 69,2) and care-
fully draw it downwards.
Opening:
 Hold the bottom rod (Fig. 69,2) of the Roman shade in the centre and care-
fully slide the Roman shade upwards.
Insect screen The insect screen is located in the upper window frame.
Closing:
 Pull insect screen at the handle (Fig. 69,1) downwards.
 Move the insect screen continuously.
If the insect screen is not drawn fully to the bottom, the Roman shade can be
stretched up to the end of the side window frame.
Opening:
 Move insect screen at the handle (Fig. 69,1) fully upwards.
Fig. 69 Hinged window
