185Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Wheels and tyres
13
13.6.3 Spare wheel support at the rear of the vehicle
(Averso nature)
Removing the spare wheel: Insert key into the locking cylinder (Fig. 230,1) of the turnbuckle and turn a
quarter turn. The turnbuckle is unlocked.
Remove key.
Fold the handle of the turnbuckle (Fig. 231,2) downwards and unhook the
turnbuckle hook (Fig. 231,3) from the slots (Fig. 231,4) on the cover.
Bend the cover (Fig. 231,1) slightly and remove from the tyre.
Remove cover plate (Fig. 232,1). Do this by removing the rubber
expanders (Fig. 232,2) from the tyre
Unscrew three securing bolts (Fig. 233,2).
Remove spare wheel (Fig. 233,1).
13.7 Tyre pressure
Fig. 230 Spare wheel support at the
rear of the vehicle
Fig. 231 Cover lock
Fig. 232 Cover plate Fig. 233 Securing the spare wheel
X Tyres overheat if the tyre pressure is too low. This can cause serious
tyre damage.
X Check tyre pressure before a journey or every 2 weeks. Wrong tyre
pressure causes excessive wear and can lead to damage or even to tyre
burst. You can lose control of the vehicle.
X Use only valves that are approved for the specified tyre pressure.
Z Only check the tyre pressure on cold tyres.
