Burstner Premio - Toilet with Fixed Seat

150 Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Sanitary fittings
10
10.8.3 Toilet with fixed seat
The flushing of the toilet is fed from the water system of the vehicle.
Flushing:
 Before flushing open the sliding trap of the Thetford toilet. To do this, turn
the slide lever (Fig. 195,1) in an anticlockwise direction.
 For flushing, press the blue flush button (Fig. 196,1).
 After flushing close the sliding trap. To do this turn the slide lever
(Fig. 195,1) in a clockwise direction.
The indicator lamp (Fig. 196,2) lights up whenever the sewage tank has to be
emptied.
Fig. 195 Thetford toilet Fig. 196 Flush button/indicator lamp
Thetford toilet
