Burstner Premio - Round Seating Group with Bed Widening

80 Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Living
6
6.14.6 Round seating group with bed widening
 Convert the table (Fig. 107,3) to a bed foundation (see section 6.12).
 Unlatch and fold up the bedding box extension (Fig. 107,9).
 Place support (Fig. 108,10) into the holder on the bedding box extension.
 Remove the back cushions (Fig. 108,1, 5, 6, 7 and 8) and lay them aside.
 Place the additional cushion (Fig. 109,11) between the seat cushions
(Fig. 109,2 and 4).
 Lay the additional cushion (Fig. 109,12) on the bedding box extension
(Fig. 109,9).
Z Depending on the model, the seating group can be different in shape and
position to the one shown here.
Fig. 107 Prior to conversion
Fig. 108 During conversion
Fig. 109 After conversion
1 Back cushion
2Seat cushion
3Table
4Seat cushion
5 Back cushion
6 Back cushion
7 Back cushion
8 Back cushion
9 Bedding box extension
10 Support
11 Additional cushion
12 Additional cushion
