Burstner Premio - Page 181

181Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Wheels and tyres
13
Rim type Tighten-
ing
torque
Type
Shaft length (SL)
Length (L)
of wheel bolt
[mm]
No. of
holes/
Bolt circle/
Centre hole-
∅
of rim
[mm]
Width
across
flats
Steel 4-hole 90 Nm
(67 ft/lbs)
Cone washer 60°
M12x1,5 Q 8.8
Flange ∅ 22
(Tol. +1.5/-0.5)
SL 24
L 42 (Tol. +1/-0.5)
4/100/- 19
Steel 5-hole 90 Nm
(67 ft/lbs)
Spherical R12
M12x1,5 Q 8.8
Flange ∅ 24 (Tol. -2)
SL 25
L 44 (Tol. +1/-0.5)
5/112/- 19
Light alloy
4-hole
OJ13/4, 14/4
120 Nm
(89 ft/lbs)
Cone washer 60°
M12x1,5 Q 10.9
Flange ∅ 21 (Tol. +0.5)
SL 28
L 48 (Tol. ±0.5)
4/100/- 17
Light alloy
4-hole
GSM1-1460-
403T1
120 Nm
(89 ft/lbs)
Cone washer 60°
M12x1,5 Q 10.9
Flange ∅ 23
SL 28
L53.5
4/100/- 17
Light alloy
5-hole
OJ14/5,15,5
120 Nm
(89 ft/lbs)
Cone washer 60°
M12x1,5 Q 10.9
Flange ∅ 21 (Tol. +0.5)
SL 28
L 48 (Tol. ±0.5)
5/112/- 17
Light alloy
5-hole
GSM1-1460-
512T2
120 Nm
(89 ft/lbs)
Cone washer 60°
M12x1,5 Q 10.9
Flange ∅ 23
SL 28
L53.5
5/112/- 17
