Cadex Electronics Inc. C7000-C Series Battery Analyzers .
140
Level 2
Password protected (high); most programming choices are locked
Display 80-character LCD, backlit; each station also features RUN, READY, FAIL signal lights
Data Ports USB port: to connect to PC for BatteryShop™ and USB label printers.
Serial port – to print to label printers
Throughput
QuickSort™
Full service
30-40 batteries/hr
Fleet of 80 batteries typical
60-80 batteries/hr
Fleet of 160 batteries typical
Throughput on full service is based on recommended monthly maintenance. Each analyzer
services two battery batches every 24h (day and night run), 20 days per month.
Physical
Length
Width
Height
Weight
12.1”; 312mm
9,4”; 240mm
3.5”; 90mm
7.1lb.; 3.2 kg
14.4”; 360mm
11.0”; 280mm
3.8”; 100mm
10.05lb.; 4.54kg
15.4"; 398mm
11.0"; 280mm
4.2"; 107mm
12.1lb; 5.5kg
Environmental
Operating temperature 41
°
F to 95
°
F; 5
°
C to 35
°
C
Storage temperatures –40
°
F to 167
°
F; -40
°
F to 75
°
C
Firmware Upgradeable with BatteryShop, flash memory. Lifetime upgrade sub scription available.
Approvals Tested and approved by ITS and TUV to comply with CSA/UL/CE/PSE standards. (PSE not
available on C7400ER)
Warranty Cadex warrants the analyzer against defective materials and workmanship for a period of
two (2) years from the original purchase date.
* 6A charge/discharge current is only available with specialized / customer adapters.
