Cadex Electronics Inc. C7000-C Series Battery Analyzers .
the highest capacity (ensure that it is 100% or greater) and the highest resistance and
run this battery through the Q-Learn program. After the Q-Learn program is complete,
take the same battery in the same adapter and run it through the QuickTest program. The
final SoH (state of Health) result should be 100%. If the result is less than 100%, erase
the battery matrix (press F
N
and then press
2) and start over. When a successful result
has been obtained (100%), test the other batteries with the same capacity to ensure that
the SoH readings are within an acceptable range.
The battery matrix will be erased if anything in the C-Code is changed except for the target
capacity and the actual program (i.e Auto, Charge, Prime, QuckTest
or any of the other
programs).
QuickTest™
C7000-C series firmware and C7000 series firmware version 6.00 and 6.11 and ) will
not display or use a matrix made with firmware version 5.00 or below. Therefore, run
the Learn program again to create a new matrix. An old matrix will not be displayed.
Ensure that battery contacts and adapter contacts are clean. Dirty contacts will affect
QuickTest readings.
Note: QuickTest is available only when using 16k Battery Adapters. These adapters are
marked ‘16K’ on the rear of the adapter.
QuickTest matrices created by the Q-Learn and the Learn programs are stored in Battery
Adapters as part of the C-Code and can be copied to other adapters. However, any
change made to the C-Code (except target capacity and selected program) erases the
stored QuickTest matrix.
Function: Before running QuickTest, create a matrix for the battery using the Learn
program (see Learn, page 34). QuickTest determines the battery SoH (state of health)
that is an approximation of the battery capacity and resistance. If a matrix does not exist
for the C-Code, (i.e. no batteries of the same model have gone through the Q-Learn or
Learn programs) a message appears stating that no QuickTest matrix has been found,
and that the Learn program should be run first. QuickTest can still run without a matrix but
results are unreliable.
