Cadex Electronics Inc. C7000-C Series Battery Analyzers .
66
DB-9 to DB-9
DB-9 DB-9
RD 2 — 3 TD
TD 3 — 2 RD
CTS 8 — 7 RTS
RTS 7 — 8 CTS
SG 5 — 5 SG
Note When connecting to a serial printer, it may also
be necessary to jumper pins 6 (DSR), 1 (DCD), and
4 (DTR) together on the printer’s DB-9 connector.
Other jumpers may be also required. Check the
printer manual for specific information.
Security
The Cadex analyzer offers three security levels for protection against tampering: Level 0
(off), Level 1 (low), and Level 2 (high). Level 0 is the default. Depending on the security
level chosen, a password is required for some features.
A password must have at least three digits.
Security Level Functions
The table below shows functions that require a password at each of the three security
levels:
Functions Level 0
(Off)
Level 1
(Low)
Level 2
(High)
Services Start Services
ü ü ü
C-Code Edit C-Codes
ü û û
Select C-Codes
ü ü û
System Setup Change Time/date
ü û û
Select Serial and
USB Port devices
ü ü û
Perform Calibration
ü ü ü
Program
Settings
Change Program
Settings
ü ü ü
