Appendix C
Specifications
Hardware
Battery Analyzers
C7200-C C7400-C C7400ER-C
Part Numbers
07-720-0100 07-740-0100 07-740-1100
Independent stations 2 4 4
Battery voltage 1.2-16V 1.2-16V Li-ion and SLA 1.2-36V
NiCd and NiMH: 1.2 – 28.8V
Charge/discharge current 100mA-4A 100mA -4A 100mA-6A*
Accuracy +/- 1% at max rated voltage, +/- 2% at 4000mA
Services batteries up to 24Ah. If set above 4A*, the current automatically scales down.
Maximum charge power 40W per station; 40W
total
55W per station; 80W
total
75W per station; 170W total
Maximum discharge power 35W per station; 70W
total
35W per station; 140W
total
75W per station; 200W total
Power management On high load demands, the current scales down; large batteries may go on waiting queue
Line voltages 100-240VAC, 50-
60Hz; 1.5A max
100-240VAC, 50-
60Hz, 1.75A max
100-120/200-240VAC, 50-60Hz; 4A
max
Chemistries Lithium-ion, nickel-metal-hydride, nickel-cadmium; lead-acid
Charge method Automatic full charge detection, safe termination under all conditions. Temperature
controlled.
Lithium-ion and lead-acid: constant voltage with current limit. Nickel-based: constant current
with Reverse Load adjustable from 5-12%. Customized charge methods possible.
Discharge method Constant discharge current to end-of-discharge voltage threshold
Battery Adapters Custom and universal SnapLock™ adapters. Each adapter holds up to 10 C-Codes to
service different battery types. Re-programmable with menu function. Temperature
controlled.
Security
Level 0
Level 1
Open, no programming restrictions (default)
Password protected (low); allows C-Code selection and display options
