Figure 73: Single Boiler Hydronic Heating & Direct Storage Tank Zoned Piping Arrangement
Central Heating Mode: 0
DHW Mode: 1 or 2
Boiler Address: Boiler Address = 100
Cold
Water In
DHW
Sensor
Union
Direct DHW Tank
Anti-Scald Mixing Valve
Cold
Water In
Hot
Water Out
