Camus Hydronics DynaMax DMH081 - PART 15 ELECTRICAL DIAGRAMS; DM 80-250 Internal Wiring Diagram (Wall Hung)

77
Ref
#
Name of Part Part ID
DynaMax Models
ALL 80 100 150 200 210 250 260 299 399 500 600 700 800
14
Hydronic
Heating/
Combination
Pump
110223-305 X X
110223-307 X X X
PL30 X X X
PL36 X X
E12 X
E30 X X
DHW Pump
E7B X X
E9B X X X X X
E12B X X
E33B X
127091.1.1 X X X
15 Mixing Chamber
GM20-70-011-01
X X X
GM20-70-020-02
X X X X X X
14-5540 X X X
16
Air Pressure
Switch
8021205256 X
17
3-Way Valve
Actuator
VC4011ZZ02/E
X X X X X X X X
FSLF24 X X X X X
3-Way Valve
Body
VCZMR6100/E
X X X X X X X
VCZND6100/U X
VBN3EM3POX
X X
VBN3FP3POX X X X
18 High Limit
TCL 110A
(CPVC, AL29-
4C, SS)
X
TCL 085A (PVC)
X
19 ¼ Turn Lock
Wall Hung X
Floor Mount X
20
Wall Mount Back
Panel
14-5402 X X X
14-5402-250 X X
21
Wall Mount Front
Bottom Wrap
14-5403 X X X
14-5403-250 X X
22
Front Upper
Wrap
14-5404 X X X
14-5404-250 X X
23 Restrain 14-5405 X X X X X
24 Mounting Bracket 14-5406 X X X X X
25 Lower Bracket 14-5407 X X X X X
26 Wall Top Bracket 14-5408 X X X X X
27
Support Frame
Assembly
14-5409 X X X
14-5409-250 X X
28 Bracket Front 14-5410 X X X X X
29 Rear Bracket 14-5411 X X X X X
30
Bezel Stiffener
Plate
14-5412 X X X X X
31 Controller Plate 14-5413 X X X X X
