Camus Hydronics DynaMax DMH081 - PART 15 ELECTRICAL DIAGRAMS (Continued); DM 210-299 Internal Wiring Diagram (Floor Mount)

78
Ref
#
Name of Part Part ID
DynaMax Models
ALL 80 100 150 200 210 250 260 299 399 500 600 700 800
32
Electrical Conduit
Plate
14-5415 X X X
14-5415-250 X X
33
Electrical Strip
Plate
14-5416 X X X X X
34 Plastic Bezel 15-6001-A X X X X X
35
Bracket for
Neutralizer Box
14-5419 X X X X X
36
Air Inlet/ Vent
Adapter
FSA-HEX03 X X X X X X X X X
37
Plate Heat
Exchanger
(Combination
Models ONLY)
LB31-20X X X X
LB31-40X X X X X X X X
38
DynaMax Floor
Front Panel
14-5501-20-25 X X
14-5501 X X X X X X
39
DynaMax Floor
Base Panel
14-5502 X X X X X
14-5502-60-75 X X X
41 Floor Back Panel
14-5504-20-25 X X
14-5504 X X X
14-5504-60-75 X X X
42 Top Cover Back
14-5505 X
X X X X
14-5505-60-75 X X X
43 Side Panel Right
14-5506-20-25 X X
14-5506 X X X
14-5506-60-75 X X X
44 Side Panel Left
14-5507-20-25 X X
14-5507 X X X
14-5507-60-75 X X X
45
Front Panel
Bottom
14-5508 X X X X X X X X
46
Side Panel Left
Front
14-5509-20-25 X X
14-5509 X X X X X X
47
Control Panel
Plate
14-5510 X X X X X X X X
48
HX Support
Frame
14-5511 X X X
14-5511-60-75 X X X
49 Support Plate 14-5512 X X X X X X X X
50 Bracket Right
14-5513-20-25 X X
14-5513 X X X X X X X X
51 Stand Off Left 14-5514 X X X X X X X X
52 Stand Off Right 14-5515 X X X X X X X X
53 Support Leg
14-5516 X X X X X
14-5516-60-75 X X X
54
Stiffener under
Leg
14-5517 X X X X X X X X
14-5517-60-75 X X X
